KRD100 Incline Impact Tester

KRD100 series incline impact tester is a testing machine that evaluates the ability of loads to withstand inclined impacts or crushing forces due to the force of gravity. These impacts and forces can affect the stability and safety of the packaging products. KRD100 series inclined impact tester can prevent these problems from affecting the goods being transported and loaded, thereby avoiding shock damages.

It can simulate packaging and packaging containers, horizontal shock and bump environment in the process of transportation, handling, stacking of shelves, sliding of motors, loading, and unloading of locomotives. This inclined impact test machine is suitable for incline impact test in the industries like packaging technology centers, manufactory of packages, transportation, scientific research institutions, etc. KRD100 complies with the international standard ISO 2248 and ISTA relevant standards.

FEATURES OF KRD100 INCLINE IMPACT TESTER


  • PLC-based stable control system: fully automatic remote-control interface, easy operation

  • Color touches screen operation, which can display the end impact speed

  • High-performance steel welded frame and solid wood shock panel, high strength and hardness and high impact resistance, low noise

  • Hard wooden or iron sliding table, effectively protect the surface of the test piece

  • Flexible positioning scroll wheel, easy to fix the position easily and realize the required speed change value

  • Driven by a motor, with simple structure and high reliability, no pollution

  • Complete control and measurement system, simple and convenient operation, integrated control and measurement

  • The customer only needs to fix the machine on the ground during installation, without other complicated operations or installation

TECHNICAL SPECIFICATIONS OF KRD100 INCLINE IMPACT TESTER


Model

KRD

KRD

KRD

KRD

KRD

KRD

KRD

Parameters100-100100-200100-300100-500100-1000100-2000100-3000

Max Load

(kg)

100

200

300

500

1000

2000

3000

Working Table Size (mm)

1100×1100

1300×1300

1800×1800

2000×2000

2200×2200

Shock Panel Size

(mm)

1600×2000

2100×2000

2000×2200

2400×2400

2600×2600

Shock Velocity Range (m/s)

1.2~3.87

0.59~2.35

Incline Angle

10°±1°

Shock Velocity Error

≤±5%

Power Supply

3-phase AC380V±10% 50Hz

Working Environment

Temperature range 0 ~ 40℃, Humidity≤80% (non-condensing)

Installation Condition

Special foundation or embedded chemical anchor bolts or expansion bolts on the leveled concrete floor

Standards

ISO 2244       ISTA

Note: The parameters in the table are for reference only, and the parameters agreed upon by the supplier and the buyer shall prevail.



TABLE OF KRD100 INCLINE IMPACT TESTER

KRD101 series packaging compression tester is the ideal equipment for the compression strength test of various packaging containers with the features of advanced technology, complete functions, reliable performance, easy control and operation. It is designed to assess the performance of a package in terms of its strength or of the protective ability it offers to its contents when it is subjected to compressive forces. KRD101 compression tester is suitable for determining the resistance to compression on materials such as boxes, paper, cardboard and corrugated fiberboard, bulk containers, pallets, components and load units. This compression tester is essential testing equipment for packaging industry, manufacturing enterprises, construction units, product quality supervision and inspection institutes, and building materials product testing departments.

TABLE OF KRD100 INCLINE IMPACT TESTER
