KRD17 Bidirectional Vertical Shock Test System

KRD17 series is a new designed fully automatic pneumatic lifting bidirectional shock test system with high degree of automation, simple operation and convenient maintenance. It is a bidirectional vertical shock test system developed for measuring and determining the impact resistance of large specimens without turning over them, and assesses the functional reliability and structural integrity of the specimens. It is especially used in the field of battery testing, can perform various conventional classic vertical upward and downward shock tests in one test table to realize the shock wave and impact energy suffered by the product in the actual environment. This equipment meets standards of IEC68-2-27, MIL-STD-202, MIL-STD-750, MIL-STD-810, MIL-STD-883, UN38.3 and other battery testing standards.

FEATURES OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM


  • Circulating storage cylinder: strong impact, fast speed, and low air consumption

  • Adopt full pneumatic drive: simple structure, high reliability, no pollution

  • Bidirectional shock test: effectively complete the upward and downward shock tests without turning over UUT

  • Multiple functions: to complete the bidirectional shock and bump tests by one clamping, with high efficiency

  • High degree of automation: After the height setting is completed, the software automatically lifts the working table to the set height, with high accuracy and good repeatability

  • Multi-track guide pillar: combined with pneumatic balance lifting system, no noise, fully automatic positioning table

  • Built-in pneumatic brake mechanism, safe and reliable

  • High-performance buffer and vibration isolation device, no special foundation is needed, and it is easy to install

TECHNICAL SPECIFICATIONS OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

Model

KRD

KRD

KRD

KRD

KRD

KRD

KRD

Parameters17-5017-10017-20017-50017-80017-100017-2000

Rated Load (kg)

50

100

200

500

800

1000

2000

Table Size (mm)

500×500

600×600

800×800

1000×1000

1200×1200

1500×1500

2000×2000

Shock Direction

Downward


Peak Acc. (g)


Half-Sine

10-750

10-600

10-450

10-300

10-250

10-200

10-150

Post-Peak

Sawtooth

10-200

10-200

10-100

10-100

10-100

10-100

10-100

Trapezoid

15-200

15-200

15-100

15-100

15-60

15-60

15-50

Pulse Duration (ms)

Half-Sine

1.5-60

2-60

2.5-60

4-60

4.5-60

5-60

6-60

Post-Peak

Sawtooth

3~18

6~18

Trapezoid

3~18

3~18

6~18

Shock Direction

Upward

Shock Wave

Half Sine Waveform

Peak Acceleration (G)

15-350

15-300

15-200

15-150

15-100

15-100

15-75

Pulse Duration (ms)

3.5-60

3.5-60

4-60

4.5-40

5.5-60

5.5-60

6-60

Overall Dimension (mm)

1250×1250×1600

1250×1250×1600

1300×1300×1700

1350×1350×1750

1550×1550×1750

1650×1650×1850

2000×2000×1900

Weight (kg)

3000

3200

3500

4500

5000

6000

8000

Power

1-phase AC220V±10% 50Hz

Air Source

≤1MPa

Installation Condition

Foundation-free, the cement floor shall be leveled and the working distance of 800 ~ 1000mm shall be reserved around the equipment

Working Environment

Temperature range 0 ~ 40℃, Humidity≤80% (non-condensing)

Standards

IEC68-2-27  MIL-STD-202 MIL-STD-750 MIL-STD-810 MIL-STD-883 UN38.3  IEC62281  IEC62133-2  UL2054  IEEE1625  SAEJ2929  IEC62660-2  ISO12405-3  UL2580

Note: 1. The parameters in the table are for reference only, and the parameters agreed upon by the supplier and the buyer shall prevail.

2. Post-peak Sawtooth and Trapezoid waveforms are optional.


TABLE OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

This bidirectional shock test table is composed of a circulating air storage cylinder, a pneumatic self-locking control mechanism up and down each, a forward impact plate, a reverse impact plate, a locking mechanism, a base, and other parts.


The circulating accumulator is used as the shock power cylinder. The pneumatic brake device locks the table at the set position. The circulating accumulator is inflated. After the air pressure reaches the set value, the locking device is controlled to release, and the circulating storage cylinder drives the table to accelerate upward and downward movement, and impacts the waveform generator on the impact plate to produce the required shock waveform.

TABLE OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

DUAL MASS SHOCK AMPLIFIER OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

The shock amplifier is a device that uses the rebound energy of the ordinary impact shock table to realize the opposite impact between the servo table and the seat on the amplifier so that the impact acceleration is multiplied.

DUAL MASS SHOCK AMPLIFIER OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

WAVE GENERATORS OF KRD17 BIDIRECTIONAL VERTICAL SHOCK TEST SYSTEM

KRD17 series bidirectional shock test system is equipped with a half-sine wave generator. The half-sine wave generator is mainly made of engineering rubber (considering the stiffness and cohesive force of rubber) and felt pads of various thicknesses. Different thicknesses are connected in series to form multiple stiffnesses to achieve different shock pulse widths. Optional for post-peak sawtooth wave generator which is lead cone; trapezoidal wave generator air source is high-pressure nitrogen, the pressure range is 1-10MPa, and the overload value can be adjusted between 10-100g, as shown in the following figure:

half sine wave generator
half sine wave generator
post peak sawtooth wave generator
post peak sawtooth wave generator
trapezoidal wave generator
trapezoidal wave generator
